Hieu test 121

Home Products ALUMINUM BUILDING WIRE222 Hieu test 121

UL Type USE-2 / RHH / RHW-2, 8000 Series Aluminum Conductor, 90°C Dry or Wet, Rated 600

Category 1 Short Name4

Category 1.1 Short Name3

Category 1.2 Short Name2

Test 1

Test 1.1

Test 1.1.1

Hanh Test CWC 3

Test 3.1

Test 3.1.1

Test 3.1.1.2

TYPE MC

SHORT A 1

SHORT A 2

SHORT A 3

SHORT A 4

SHORT A 5

ALUMINUM BUILDING WIRE222

SHORT B 1

SHORT B 2

SHORT B 3

SHORT B 4

SHORT B 5

SHORT NAME lv1

CATEGORY NAME LV2

SHORT NAME lv3

Son test hehe 24/03 (1)

CWC SHORT NAME HIHI

CWC CATEGORY NAME LV2

CWC SHORT NAME HEHE

Son test menu hihi12345 (1)

Hieu Shortname 3.3-1

Hieu Shortname 3.3-2

Hieu Shortname 3.3-4

Hieu Shortname 3.3-5

Hieu Shortname 3.3-6

Hieu Shortname 3.4-1

Hieu Shortname 3.4-2

Hieu Shortname 3.4-4

Hieu Shortname 3.4-5

Hieu Shortname 3.4-6

SHORT TEST 1

SHORT TEST 2

SHORT TEST 3

SHORT TEST 4

SHORT TEST 5

Hieu test doi ten

Bare Aluminum Cables

Cables Overhead

AWG 62289

Drop Cables - Duplex

Drop Cables - Quadruplex

URD Cables (Underground)

URD Duplex UL Type USE-2, 1350 Aluminum Conductors, 90°C Dry or Wet, Rated 600 V (4)

MEDIUM VOLTAGE CABLES

SO PORTABLE CORD

Hieu Category

Test Category 7u8

Select a section

UL Type USE-2 / RHH / RHW-2 conductors are used in conduit and direct burial (as UL Type USE-2) for services, feeders, and branch circuits in residential, commercial or industrial applications in accordance with the NEC. When used as UL Type USE-2 or RHW-2, the conductor is suitable for use in dry or wet locations at temperatures not to exceed 90°C. When used as UL Type RHH, the conductor is suitable for use in dry locations at temperatures not to exceed 90°C. The conductor is rated 600 V.

Conductors:
Annealed compact stranded AA-8000 series Aluminum Conductor Material (ACM).
Insulation:
Abrasion, moisture, heat, and sunlight resistant colored crosslinked polyethylene (XLPE).

Colored XLPE

600 V

90°C Dry or Wet

Overall Diameter Less than or Equal to 1.000 in
Not Under Tension: 4x outer diameter
Under Tension (During Pull): 6x outer diameter
Overall Diameter Greater than 1.000 in
Not Under Tension: 5x outer diameter
Under Tension (During Pull): 7.5x outer diameter

Sunlight resistant and marked
RoHS Compliant

ASTM B800 -- 8000 Series Aluminum Alloy Wire for Electrical Purposes—Annealed and Intermediate Tempers
ASTM B801 -- Concentric-Lay-Stranded Conductors of 8000 Series Aluminum Alloy for Subsequent Covering or Insulation
UL 44 -- Thermoset-Insulated Wires and Cables (RHH / RHW-2)
UL 854 -- Service-Entrance Cables (USE-2)
ICEA S-95-658 / NEMA WC70 -- Power Cables Rated 2000 Volts or Less for the Distribution of Electrical Energy
Federal Specification AA-59544
Federal Specification JC-30B

UL listed as Type USE-2 -- File E487841
UL listed as Type RHH / RHW-2 -- File E487972
